Delta ASD-A2 Series ECMA-E11310SS 1kW 20 Bit Incremental Encoder 2000RPM with Brake 4.77 Nm, 130mm flange, 22mm shaft Servo Motor
- Brand: Delta Electronics
- SKU: ECMA-E11310SS
- MPN: ECMA-E11310SS
- Price: 29975.13 TRY + VAT · incl. VAT 35970.16 TRY
- Availability: In stock
- Servo Motors
- Delta Electronics Servo Motors
- Selection guide: Servo Motors Selection Guide
Delta ASD-A2 Series ECMA-E11310SS 1kW 20 Bit Incremental Encoder 2000RPM with Brake 4.77 Nm, 130mm flange, 22mm shaft Servo Motor. Servo Motors are used in packaging, CNC, robot and precision positioning axes. Technical data: Power 1 kW, Servo Motor Brake Type With Brake. Stock code: ECMA-E11310SS.
| Power | 1 kW |
|---|---|
| Servo Motor Brake Type | Frenli |
| Rated Torque | 4.77 N-m |
| Maximum Torque | 14.3 N-m |
| Rated Speed | 2000 r/min |
| Maximum Speed | 3000 r/min |
| Rated Current | 5.6 A |
| Maximum Current | 16.8 A |
| Gram | 8.4 kg |
| Brake Holding Torque | 10.0 N-m (min) |
| Encoder Type | 20-bit artımlı (incremental) |
| Flange Size | 130 mm |
| Shaft Diameter | 22 (+0 / -0.013) mm |
| Insulation Class | Class A (UL), Class B (CE) |
| IP Rating | IP65 (yağ keçeli model) |
| Operating Temperature | 0 ºC ~ 40 ºC |
| Storage Temperature | -10 ºC ~ 80 ºC |
| Shaft Type | Kamalı (vida delikli), yağ keçeli |
