KSN KÇK-6006 Fork Insulated Terminal M6 4-6 mm2 Yellow

• Brand: KSN
• SKU: KSN3153
• MPN: KÇK-6006
• Price: 417.90 TRY + VAT · incl. VAT 501.48 TRY
• Availability: In stock
• Fork Type Insulated Cable Terminals
• KSN Fork Type Insulated Cable Terminals
• Selection guide: Fork Type Insulated Cable Terminals Selection Guide: Technical Criteria and Engineering Practice

The KSN KÇK-6006 is a yellow, PVC-insulated fork-type terminal with a fork (U) end, used to connect conductors with a 4-6 mm² (12-10 AWG) cross-section to M6 bolted connection points. Housing material is tin-plated copper; insulation is PVC, and the catalog gives a maximum operating temperature of 105 °C and a voltage of 600 V. Dimensions according to the catalog dimension drawing: fork opening (d2) 6.4 mm, B 12.0 mm, total length (L) 31.2 mm, F 12.0 mm, inner diameter (d1) 3.6 mm, D 6.7 mm, H 13.0 mm, metal thickness (s) 1.0 mm. The catalog states that the funnel shape of the nylon sleeve allows easy entry of the conductor. The product is listed in the catalog as a box of 100; sales are made in quantities of 100 and multiples. Used as a cable lug in bolt-fastened connections such as panels, motors and busbars.
