KSN KYK-401 Ring Insulated Terminal M4 0.5-1.5 mm2 Red
- Brand: KSN
- SKU: KSN3123
- MPN: KYK-401
- Price: 258.80 TRY + VAT · incl. VAT 310.56 TRY
- Availability: In stock
- Ring Type Insulated Cable Terminals
- KSN Ring Type Insulated Cable Terminals
- Selection guide: Ring Type Insulated Cable Terminals Selection Guide: Technical Criteria and Engineering Practice
The KSN KYK-401 is a red, PVC-insulated ring-type terminal with a round end, used to connect conductors with a 0.5-1.5 mm² (22-16 AWG) cross-section to M4 bolted connection points. Housing material is tin-plated copper; insulation is PVC, and the catalog gives a maximum operating temperature of 105 °C and a voltage of 600 V. Dimensions according to the catalog dimension drawing: hole diameter (d2) 4.3 mm, B 8.0 mm, total length (L) 21.5 mm, F 7.0 mm, inner diameter (d1) 1.6 mm, D 4.3 mm, H 10.0 mm, metal thickness (s) 0.8 mm. The catalog states that the funnel shape of the nylon sleeve allows easy entry of the conductor. The product is listed in the catalog as a box of 200; sales are made in quantities of 200 and multiples. Used as a cable lug in bolt-fastened connections such as panels, motors and busbars.
| Cable Terminal Type | Yuvarlak Tip |
|---|---|
| Ferrule Size | 0.5–1.5 mm |
| Ferrule/Lug Insulation | İzoleli |
| Color | Red |
| Cable Cross-Section | 0,50 - 1,50 mm² / 22 ~ 16 AWG |
| Bolt Size | M4 |
| Standard | DIN 46237 |
| Material | Bakır, Kalay Kaplı |
| Isolation | PVC |
| Operating Temperature | Maksimum 105 °C |
| Voltage | 600 V |
| Hole Diameter | 4.3 mm |
| Dimension B | 8 mm |
| Length | 21.5 mm |
| Dimension F | 7 mm |
| Inner Diameter | 1.6 mm |
| Dimension D | 4.3 mm |
| Dimension H | 10 mm |
| Thickness | 0.8 mm |
| Features | Naylon kovanın huni şekli, iletken kablonun kolay girişini sağlar |
