Schneider Electric A9E18320 iIL Single Pilot Light, Red
- Brand: Schneider Electric
- SKU: A9E18320
- MPN: A9E18320
- Price: 795.08 TRY + VAT · incl. VAT 954.10 TRY
- Availability: Made to order
- Push Buttons
- Schneider Electric Push Buttons
- Selection guide: Push Buttons Selection Guide: Technical Criteria and Engineering Practice
- Schneider Electric A9E18320 Teknik Veri Föyü (PDF)
Schneider Electric A9E18320 iIL Single Pilot Light, Red. Technical specifications of this model: Color: Red
| Color | Red |
|---|---|
| Series | Acti9 |
| Product Type | Modüler pilot ışığı |
| Rated Control Supply Voltage (Us) | 110…230 V AC @ 50/60 Hz; 110…130 V DC |
| Mounting Type | Fixed |
| Mounting Support | Simetrik DIN rayı |
| Comb Busbar Compatibility | Yukarı doğru: ProDis |
| Number of 9 mm Pitches | 2 |
| Height | 82 mm |
| Width | 18 mm |
| Depth | 69.5 mm |
| Cable Stripping Length | 9 mm |
| Tightening Torque | 1 N.m |
| Standards | IEC 60947-5-1 |
| IP Rating | IP2; IPxx B |
| Pollution Degree | 3 |
| Tropical Climate Resistance | 2 |
| Relative Humidity | 95 % @ 55 °C |
| Operating Ambient Temperature | -35…70 °C |
| Storage Temperature | -40…80 °C |
