Schneider Electric CCT15245 IC Astronomical time switch 2 contact, 7 days
- Brand: Schneider Electric
- SKU: CCT15245
- MPN: CCT15245
- Price: 14900.72 TRY + VAT · incl. VAT 17880.86 TRY
- Availability: Made to order
- Astronomical Timer Relays
- Selection guide: Astronomical Timer Relays Selection Guide: Technical Criteria & Application Standards
- Schneider Electric CCT15245 Teknik Veri Föyü (PDF)
Schneider Electric CCT15245 IC Astronomical time switch 2 contact, 7 days. Technical specifications of this model: Manufacturer Product Group: Control products
| Manufacturer Product Group | Kontrol ürünleri |
|---|---|
| Product Type | Programlanabilir astronomik alacakaranlık anahtarı |
| Channel Count | 2 |
| Adjustment Type | Haftalık programlama |
| Device Application | Bina |
| Power Consumption (W) | 0,5 W standby |
| Maximum Switching Current | 10 A - 250 V AC pf = 0,6; 16 A - 250 V AC pf = 1 |
| Minimum Switching Current | 10 mA 230 V AC; 100 mA 24 V AC/DC |
| Rated Operational Voltage (Ue) | 230 V AC +10 % -15 % @ 50/60 Hz |
| Contact Arrangement | C/O |
| Control Type | Gün doğuş/batış zamanlarının hesaplanmasıyla kontrol |
| Accuracy | +/- 0.25 s/day 25 °C |
| Operating Mode | İyi akşamlar, sabah; Akşam kapalı, sabah pasif; Yalnızca zamanlayıcı anahtarı etkin |
| Display Type | Arkadan aydınlatmalı LCD |
| Displayed Information | Süre; Operating time counter (kanal başına); Switching behaviour; Gün |
| Mounting Support | TH35 DIN rayı (EN 60715) |
| Connection Terminals | 2 x 0,5…2,5 mm² vidalı terminaller katı veya esnek; 1 x 2,5 mm² vidalı terminaller solid or flexible with sleeve |
| Conformity Markings | CE |
| Insulation Class | Class II |
| Height | 92.6 mm |
| Width | 45 mm |
| Depth | 66.7 mm |
| Product Weight | 141 g |
| Standards | EN 60730-2-7:2010 |
| Operating Ambient Temperature | -30…55 °C |
| IP Rating | IP20 |
| Relative Humidity | 90 %, yoğuşmasız |
