Schneider Electric METSEDM6200HCL10RS DM6200H multimeter, with Modbus communication
- Brand: Schneider Electric
- SKU: METSEDM6200HCL10RS
- MPN: METSEDM6200HCL10RS
- Price: 6805.40 TRY + VAT · incl. VAT 8166.48 TRY
- Availability: In stock
- Digital Panel Multimeters
- Selection guide: Digital Panel Multimeters Selection Guide: Technical Criteria and Engineering Practice
- Schneider Electric METSEDM6200HCL10RS Teknik Veri Föyü (PDF)
Schneider Electric METSEDM6200HCL10RS DM6200H multimeter, with Modbus communication. Technical specifications of this model: Communication Protocol: Modbus Series: Multimeters
| Communication Protocol | Modbus |
|---|---|
| Series | Multimetreler |
| Product Type | VAF PF ölçüm cihazı |
| Device Application | Uzaktan gözlemleme |
| Measurement Type | Akım; Gerilim; Frekans; RPM |
| Rated Control Supply Voltage (Us) | 48…277 V AC 45…65 Hz; 48…277 V DC |
| Mains Frequency | 60 Hz; 50 Hz |
| Rated Current (Ir) | 1 A; 5 A |
| Network Configuration | 3P + N; 3P; 1P + N; 2P + N; 2P |
| Power Consumption (VA) | 4 VA @ 240 V faz ve nötr arasında |
| Power Consumption (W) | 2 W @ 240 V |
| Display Type | 8 segment LED |
| Number of Display Digits | 12 basamak(lar) - 14,2 mm |
| Setting Tamper Protection | Erişim kodu ile korunur |
| Sampling Rate | 32 örnek/döngü |
| Measuring Current | 5–6000 mA |
| Measurement Voltage | 46…277 V AC 50…60 Hz faz ve nötr arasında; 80…480 V AC 50…60 Hz fazlar arasında; 277…999000 V AC 50…60 Hz harici VT ile |
| Frequency Range | 45–65 Hz |
| Number of Inputs | 2 |
| Measurement Accuracy | Frekans +/- %0,05; Güç faktörü +/- 0.01; Akım +/- 1 %; Gerilim +/- 1 % |
| Accuracy Class | Class 1 |
| Local Signalling | Yeşil LED: etkinlik; Kırmızı LED: çıkış sinyali 1…9999000 pulse/ k_h (kWh, kVAh, kVARh) |
| Communication Port Support | Vidalı terminal bloğu: RS485 |
| Material | Polikarbonat |
| Flame Retardancy Class | V-0 (UL 94) |
| Mounting Type | Sıva altı monte |
| Mounting Support | Gövde |
| Measurement Category | Kategori III 480 V |
| Insulation Class | Class II |
| Cable Stripping Length | Akım devresi: 3,68 mm; Gerilim devresi: 7 mm; Kontrol devresi: 7 mm; Haberleşme: 7 mm |
| Standards | IEC 61010-1:ed. 3; UL 61010-1:ed. 3 |
| Certifications | CE (IEC 61010-1); CULus (UL 61010-1); CULus (CSA C22.2 No 61010-1); C-Tick |
| Width | 96 mm |
| Depth | Dış : 13 mm; Panel : 49 mm |
| Height | 96 mm |
| Product Weight | 300 g |
| Overvoltage category | III |
| IP Rating | IP51 ön: (IEC 60529); IP30 gövde: (IEC 60529) |
| Relative Humidity | 5…95 % @ 50 °C |
| Pollution Degree | 2 |
