Schneider Electric NU360154 Yeni Unica Bluetooth Signal Receiver Socket Anthracite
- Brand: Schneider Electric
- SKU: NU360154
- MPN: NU360154
- Price: 36033.00 TRY + VAT · incl. VAT 43239.60 TRY
- Availability: Made to order
- HDMI, Audio and Speaker Sockets
- Schneider Electric HDMI, Audio and Speaker Sockets
- Selection guide: Audio and Video Sockets Selection Guide: Technical Criteria and Engineering Practice
- Schneider Electric NU360154 Teknik Veri Föyü (PDF)
Schneider Electric NU360154 Yeni Unica Bluetooth Signal Receiver Socket Anthracite. Technical specifications of this model: Series: Yeni Unica Color: Anthracite
| Color | Anthracite |
|---|---|
| Series | New Unica |
| Product Type | Ses alıcısı |
| Device Presentation | Kapak plakalı mekanizma |
| Device Mounting | Flush-mounted |
| Fixing Method | Vidalar; Tırnaklar |
| Device Arrangement | 1 audio receiver; 1 güç kaynağı |
| Connector Type | Jack (3,5 mm), 62 Ohm |
| Color Tone | Antarsit (RAL 7021) |
| Rated Operational Voltage (Ue) | Audio receiver: 15/16 V DC; Güç besleme: 265 V AC 47…63 Hz |
| Current Consumption | 4.5…100 mA Bluetooth ile; 4.5…75 mA jak ile |
| Power Consumption (W) | 12 W için güç besleme |
| Input Voltage | 100 mVrms jak ile |
| Output Voltage | 15 V DC güç besleme |
| Output Current | 800 mA güç besleme |
| Bandwidth | 45–20000 Hz |
| Transmission Frequency | 2,4 GHz |
| Connection Terminals | Screw terminals |
| Material | ABS (akrilonitril butadiyen stiren): merkezi plaka |
| Operating Ambient Temperature | 0…40 °C |
| Storage Temperature | 0…60 °C |
| Height | 45.2 mm |
| Width | 44.75 mm |
| Depth | 42.15 mm |
| Flush Mounting Depth | 33.45 mm |
| Product Weight | 0.24 kg |
| IP Rating | IP20 |
| IK Impact Protection | IK01 |
