Schneider Electric XB5FK133B5 Illuminated, Latching push button LED 24 VAC /DC Red 1NO+1NC
- Brand: Schneider Electric
- SKU: XB5FK133B5
- MPN: XB5FK133B5
- Price: 2924.54 TRY + VAT · incl. VAT 3509.45 TRY
- Availability: Made to order
- Selector Push Buttons
- Schneider Electric Selector Push Buttons
- Selection guide: Selector Push Buttons Selection Guide: Technical Criteria and Engineering Practice
- Schneider Electric XB5FK133B5 Teknik Veri Föyü (PDF)
Schneider Electric XB5FK133B5 Illuminated, Latching push button LED 24 VAC /DC Red 1NO+1NC. Technical specifications of this model: Color: Red Contact Arrangement: 1NO+1NC
| Contact Arrangement | 1NO+1NC |
|---|---|
| Color | Red |
| Series | Harmony XB5 |
| Product Type | Işıklı seçici anahtar |
| Bezel Material | Koyu gri plastik |
| Head Type | Ankastre |
| Mounting Diameter | 30.5 mm |
| Signalling Head Shape | Round |
| Operating Mechanism Type | Fixed |
| Operator Profile | Yeşil standart kol, işaretsiz |
| Operator Position Information | 3 konum +/- 45° |
| Contact Operation Type | Yavaş kesen |
| Connection Terminals | Vida kelepçesi terminalleri, <= 2 x 1,5 mm² Kablo uçlu (IEC 60947-1); Vida kelepçesi terminalleri, >= 1 x 0,22 mm² kablo uçsuz (IEC 60947-1) |
| Lamp Holder Type | Entegre LED |
| Rated Control Supply Voltage (Us) | 24 V AC/DC @ 50/60 Hz |
| Height | 42 mm |
| Width | 36.6 mm |
| Depth | 71 mm |
| Terminal Designation (ISO) | (21-22)NC; (13-14)NO |
| High-Pressure Washdown Resistance | 7000000 Pa @ 55 °C, mesafe: 0,1 m |
| Contact Usage | Standart kontaklar |
| Positive Opening | NK kontak ile (IEC 60947-5-1 ek K) |
| Mechanical Endurance | 500000 cycles |
| Tightening Torque | 0,8…1,2 N.m (IEC 60947-1) |
| Contact Material | Gümüş alaşım (Ag/Ni) |
| Short-Circuit Protection | 10 A kartuş sigortası tip gG (IEC 60947-5-1) |
| Conventional Free Air Thermal Current (Ith) | 10 A (IEC 60947-5-1) |
| Rated Insulation Voltage (Ui) | 600 V (kirlilik derecesi 3) (IEC 60947-1) |
| Rated Impulse Withstand Voltage (Uimp) | 6 kV (IEC 60947-1) |
| Electrical Reliability (IEC 60947-5-4) | Λ < 10exp(-6) @ 5 V ve 1 mA temiz ortamda (IEC 60947-5-4); Λ < 10exp(-8) @ 17 V ve 5 mA temiz ortamda (IEC 60947-5-4) |
| Light Source | Evrensel LED |
| Supply Voltage Limits | 21,6…26,4 V AC |
| Device Presentation | Angled |
| Storage Temperature | -40…70 °C |
| Operating Ambient Temperature | -40…70 °C |
| Electric Shock Protection Class | Sınıf II (IEC 60536) |
| IP Rating | IP66 (IEC 60529); IP67; IP69; IP69K |
| Enclosure Type | UL type 4X/13 |
| IK Impact Protection | IK03 (IEC 50102) |
| Standards | IEC 60947-1; UL 508; JIS C8201-5-1; IEC 60947-5-4; IEC 60947-5-1; CSA C22.2 No 14; JIS C8201-1 |
