Schneider Electric ZB4BV6 Direct Supply Pilot Light
- Brand: Schneider Electric
- SKU: ZB4BV6
- MPN: ZB4BV6
- Price: 550.44 TRY + VAT · incl. VAT 660.53 TRY
- Availability: Made to order
- Pilot Lights
- Schneider Electric Pilot Lights
- Selection guide: Pilot Light Selection Guide
- Schneider Electric ZB4BV6 Teknik Veri Föyü (PDF)
Schneider Electric ZB4BV6 Direct Supply Pilot Light.
| Series | Harmony XB4 |
|---|---|
| Product Type | Eksiksiz gövde/ışık bloğu tertibatı |
| Fixing Ring Material | Zamak |
| Connection Terminals | Vida kelepçesi terminalleri, <= 2 x 1,5 mm² Kablo uçlu; Vida kelepçesi terminalleri, >= 1 x 0,22 mm² kablo uçsuz |
| Light Source | Ampul dahil değil |
| Lamp Holder Type | BA 9 s |
| Light Block Supply Type | Doğrudan <2,4 W |
| Rated Control Supply Voltage (Us) | <= 250 V |
| Terminal Designation (ISO) | (X1-X2)PL |
| Product Weight | 0.052 kg |
| Tightening Torque | 0,8…1,2 N.m (IEC 60947-1) |
| Rated Insulation Voltage (Ui) | 600 V (kirlilik derecesi 3) (IEC 60947-1) |
| Rated Impulse Withstand Voltage (Uimp) | 6 kV (IEC 60947-1) |
| Signalling Type | Fixed |
| Device Presentation | Temel alt montajlar |
| Storage Temperature | -40…70 °C |
| Operating Ambient Temperature | -40…70 °C |
| Electric Shock Protection Class | Sınıf I (IEC 60536) |
| Standards | IEC 60947-5-5; IEC 60947-5-4; IEC 60947-1; IEC 60947-5-1; UL 508; CSA C22.2 No 14; JIS C8201-5-1; JIS C8201-1 |
| Certifications | DNV; UL listeli; LROS (Lloyds register of shipping); BV; CSA |
| Vibration Resistance | 5 gn (f= 2…500 Hz) (IEC 60068-2-6) |
| Shock Resistance | 30 gn (süre = 18 ms) için yarım sinüs dalgası hızlandırma (IEC 60068-2-27); 50 gn (süre = 11 ms) için yarım sinüs dalgası hızlandırma (IEC 60068-2-27) |
