Schneider Electric ZB6E2B NC Contact Faston
- Brand: Schneider Electric
- SKU: ZB6E2B
- MPN: ZB6E2B
- Price: 611.60 TRY + VAT · incl. VAT 733.92 TRY
- Availability: Made to order
- Push Button and Pilot Light Accessories and Spare Parts
- Schneider Electric Push Button and Pilot Light Accessories and Spare Parts
- Selection guide: Push Button and Pilot Light Accessories Selection Guide
- Schneider Electric ZB6E2B Teknik Veri Föyü (PDF)
Schneider Electric ZB6E2B NC Contact Faston.
| Series | Harmony XB6 |
|---|---|
| Product Type | Kontak bloğu |
| Contact Arrangement | 1NC |
| Contact Operation Type | Yavaş kesen |
| Contact Block Type | Tek |
| Connection Terminals | Faston konnektör |
| Contact Material | Gümüş alaşım (Ag/Ni) |
| Terminal Designation (ISO) | (1-2)NC |
| Product Weight | 0.004 kg |
| Positive Opening | Var (IEC 60947-5-1 ek K) |
| Operating Travel | 1 mm (NK değişimi elektrik durumu); 3,5 mm (toplam hareket) |
| Operating Force | 2,5 N NK değişimi elektrik durumu |
| Mechanical Endurance | 5000000 cycles |
| Short-Circuit Protection | 6 A kartuş sigortası tip gG |
| Rated Insulation Voltage (Ui) | 250 V (kirlilik derecesi 3) (IEC 60947-1) |
| Rated Impulse Withstand Voltage (Uimp) | 4 kV (IEC 60947-1) |
| Rated Operational Current (Ie) | 3 A @ 120 V, AC-15, B300; 1,5 A @ 240 V, AC-15, B300; 0,1 A @ 250 V, DC-13, R300; 0,22 A @ 125 V, DC-13, R300 |
| Electrical Reliability (IEC 60947-5-4) | Λ = 10exp(-8) @ 5 V ve 1 mA %90 güven düzeyiyle (IEC 60947-5-4) |
| Storage Temperature | -40…70 °C |
| Operating Ambient Temperature | -25…70 °C |
| IP Rating | IP20 |
| Standards | UL 508; JIS C 4520; IEC 60947-5-1; JIS C 852; IEC 60947-1; IEC 60947-5-4; CSA C22.2 No 14 |
| Certifications | GOST; CSA; UL; CCC |
| Vibration Resistance | +/- 3 mm (f= 2…500 Hz) (IEC 60068-2-6); 5 gn (f= 2…500 Hz) (IEC 60068-2-6) |
| Shock Resistance | 30 gn (süre = 18 ms) için yarım sinüs dalgası hızlandırma (IEC 60068-2-27); 50 gn (süre = 11 ms) için yarım sinüs dalgası hızlandırma (IEC 60068-2-27) |
