Unit UT5320R+ 5kV AC / 6kV DC 20mA 10GΩ Programmable Withstand Voltage and Insulation Resistance Tester
- Brand: Unit
- SKU: UT5320R+
- MPN: UT5320R+
- Price: 68522.52 TRY + VAT · incl. VAT 82227.02 TRY
- Availability: Made to order
- Electrical and Electronic Testers
- Unit Electrical and Electronic Testers
- Selection guide: Electrical and Electronic Testers Selection Guide: Technical Criteria and Engineering Practice
Unit UT5320R+ is the highest-capacity model of the UT5300+ series, performing 5 kV AC / 6 kV DC withstand tests and 0.1 MΩ to 10 GΩ insulation resistance tests with 100 VA AC output power and a 20 mA AC current limit. Technical values: AC test voltage 0.050–5.000 kV (50 Hz or 60 Hz); DC test voltage 0.050–6.000 kV; AC test current 0.001–20 mA; DC test current 0.1 µA–10.00 mA; insulation resistance 0.1 MΩ–10 GΩ; AC output power 100 VA, DC output power 60 VA; up to 10 mA and 25 VA in insulation testing; ARC detector levels 1–9; 100 test files; RS232C, LAN and optional RS485; 4.3-inch display; dimensions 295 × 117.6 × 465 mm, weight 8.3 kg. It performs AC withstand, DC withstand and insulation resistance tests individually or in a multi-item test scheme, supports higher leakage currents thanks to the 20 mA AC current limit, and discharges automatically after the test. It is used for the safety performance inspection of household appliances, transformers, electrical equipment, components, lighting and medical equipment.
| AC Test Current | 0.001 – 20 mA |
|---|---|
| AC Test Voltage | 0.050 – 5.000 kV (çözünürlük 1 V; sinüs, bozulma < %3; 50 Hz / 60 Hz seçilebilir) |
| Interfaces | RS232C, LAN, RS485 (opsiyonel); USB Host, HANDLER |
| Display Size | 4.3 inç TFT LCD |
| Channel Count | 1 |
| DC Test Voltage | 0.050 – 6.000 kV (çözünürlük 1 V; sinyal frekansı 600 Hz) |
| DC Test Current | 0.1 µA – 10.00 mA |
| Output Power | AC: 100 VA (5.000 kV, 20 mA); DC: 60 VA (6.000 kV, 10 mA) |
| Programming Accuracy | ±(%1.0 ayar değeri + 5 V) (yüksüz) |
| Voltage Accuracy | ±(%1.0 okuma + 5 V) |
| Voltage Regulation | AC: ±(%1.0 + 50 V); DC: ±(%1.0 + 100 V) (anma gücünde) % |
| ARC Detector | AC ve DC için kapalı, seviye 1 – 9 |
| Sequencing Function | Pencere karşılaştırma modu: alt limit açıksa alt limit < Ix < üst limit geçer; alt limit kapalıysa Ix < üst limit geçer; izolasyon direnci aynı mantıkla; PASS/FAIL LCD ve LED gösterimi ile sesli alarm |
| Current Upper Limit Setting | AC 0.001 – 20 mA; DC 0.1 µA – 10 mA |
| Additional Functions | 100 programlanabilir test dosyası, her dosyada 20 test adımı; çoklu madde test düzeni; toprak hattı akımı algılama, kısa devre algılama, ARC algılama, DC hızlı deşarj, otomatik OVP ve OCP; SCPI ve Modbus RTU protokolleri; bilgisayar yazılımı; endüstriyel kontrol için HANDLER (PLC) arayüzü; USB ile veri yedekleme |
| Supply Voltage | 110 V / 220 V AC (±%10), 50–60 Hz |
| Product Dimensions | 295 × 117.6 × 465 mm (G × Y × D) |
| Gram | 8.3 kg |
| Standard Accessories | Güç kablosu, kırmızı-siyah test klipsi (1 çift), yüksek gerilim çubuk test kablosu (küçük tip, anahtarsız) |
| Insulation Resistance Measurement | 0.1 MΩ – 10 GΩ |
| Maximum Output Current | 10 mA (izolasyon direnci testi) A |
| Maximum Output Power | 25 VA (2500 V / 10 mA) |
| Short-circuit Current | > 20 mA (ayarlı çıkış gerilimi > 500 V) |
| Resistance Display Range (1000 V) | 10 mA 0.1–0.5 MΩ; 2 mA 0.5–5 MΩ; 200 µA 5–50 MΩ; 20 µA 50–500 MΩ; 2 µA 500 MΩ–10 GΩ |
| Resistance Measurement Accuracy | ≥ 500 V: 1 MΩ–1 GΩ ±(%5 okuma + 5 hane), 1–10 GΩ ±(%10 okuma + 5 hane); < 500 V: 0.1 MΩ–1 GΩ ±(%10 okuma + 5 hane); 1–10 GΩ yalnız referans |
| Current Accuracy | ±(%1.5 okuma + 5 hane) (sıfırlamadan sonra) |
| Load Regulation | ≤ %1 (anma gücünde) |
| Output Ripple | ≤ %3 (1 kV, yüksüz) |
| Automatic Discharge | Test sonrası otomatik deşarj |
| Resistance Limit Setting | Üst limit: kapalı, 0.1 MΩ – 10 GΩ; alt limit: 0.1 MΩ – 10 GΩ |
