GEMO AR2-A-24VDC-14D-TR DIN Rail Smart Relay / PLC, 14 Digital Inputs, 10 PNP Transistor Outputs
- Brand: GEMO
- SKU: AR2-A-24VDC-14D-TR
- MPN: AR2-A-24VDC-14D-TR
- Price: 3968.35 TRY + VAT · incl. VAT 4762.02 TRY
- Availability: In stock
- PLC CPUs
- GEMO PLC CPUs
- Selection guide: PLC CPUs Selection Guide: Technical Criteria and Engineering Practice
GEMO AR2-A-24VDC-14D-TR is a DIN rail-type smart relay / PLC programmable with Ladder Logic. It is designed for use in automation applications with 14 digital inputs and 10 PNP transistor outputs.
| I/O Output | 10 × PNP transistör çıkış |
|---|---|
| I/O Input | 14 sayısal giriş |
| Supply Type | 18..32Vdc |
| Display | 2x16 karakter LCD, arka aydınlatmalı |
| Expandability | Available |
| Real-Time Clock | None |
| PTC Input | 2 telli PTC (-50..150 °C) |
| Programming Software | GEMO Ladder Editör |
| Communication Interface | RS-232 (yazılım aktarma), RS-485 (ağ) |
| Scan Time | en fazla 10ms |
| Digital input | OFF:0..2VDC; ON:10..32VDC, maks.32VDC, ortak (-) negatif uç (PNP/Totem Pole), izole (opto-coupler) |
| Auxiliary Supply Output | 18Vdc, maks. 50mA (sayısal girişler için) |
| Transistor Output Load | PNP transistör, maksimum 32VDC, 0.3A |
| Size Type | 125x115x65 mm (klemens soketi takılı olarak) |
| Mounting Type | Pano içi raya sabit montaj |
| Power Consumption | En fazla 6W |
| Operating Temperature | 0 .. 50 °C |
| Storage Temperature | -10 °C .. 60 °C (buzlanma olmadan) |
| Relative Humidity | 30 °C'ye kadar %80, sonra doğrusal azalarak 50 °C'de %50 (yoğunlaşmasız) |
| Operating Altitude | En çok 2000 m |
| Standards | EMC: TS EN 61000-6-2:2019, IEC 61000-6-2:2016 RLV, TS EN 61000-6-4:2020, IEC 61000-6-4:2018 RLV; Güvenlik: TS EN 61010-1:2012 + A1:2019 + A1/AC:2019 |
| IP Rating | IP20 |
| Tightening Torque | en fazla 0.5 N.m (klemens) |
