GEMO AR2-G1-24VDC-12D2A-TR Expansion Module, 12 Digital + 2 Analog Inputs, 10 Transistor Outputs
- Brand: GEMO
- SKU: AR2-G1-24VDC-12D2A-TR
- MPN: AR2-G1-24VDC-12D2A-TR
- Price: 3405.27 TRY + VAT · incl. VAT 4086.32 TRY
- Availability: In stock
- Mixed Analog and Digital I/O Modules
- Selection guide: PLC Input and Output Modules Selection Guide
GEMO AR2-G1-24VDC-12D2A-TR, expansion module for AR2-A-14D, AR2-A-12D2A and AR2-P series. Has 18..32 VDC supply, 12 digital inputs, 2 x 10 VDC analog inputs and 10 transistor outputs.
| Connection Type / Module | RS-485 / AR2-G1 genişleme modülü |
|---|---|
| I/O Output | 10 transistör çıkış |
| I/O Input | 12 sayısal giriş + 2 adet 0–10 V analog giriş |
| Supply Type | 18..32Vdc |
| LED Indicator | Available |
| Compatible Devices | AR2-A-14D, AR2-A-12D2A, AR2-P |
| PTC Input | 2 telli PTC (-50..150 °C) |
| Digital input | OFF:0..2VDC; ON:10..32VDC, maks.32VDC, ortak (-) negatif uç (PNP/Totem Pole), izole (opto-coupler) |
| Auxiliary Supply Output | 18Vdc, maks. 50mA (sayısal girişler için) |
| Transistor Output Load | PNP transistör, maksimum 32VDC, 0.3A |
| Size Type | 125x115x65 mm (klemens soketi takılı olarak) |
| Mounting Type | Pano içi raya sabit montaj |
| Power Consumption | En fazla 6W |
| Operating Temperature | 0 .. 50 °C |
| Storage Temperature | -10 °C .. 60 °C (buzlanma olmadan) |
| Relative Humidity | 30 °C'ye kadar %80, sonra doğrusal azalarak 50 °C'de %50 (yoğunlaşmasız) |
| Operating Altitude | En çok 2000 m |
| Standards | EMC: TS EN 61000-6-2:2019, IEC 61000-6-2:2016 RLV, TS EN 61000-6-4:2020, IEC 61000-6-4:2018 RLV; Güvenlik: TS EN 61010-1:2012 + A1:2019 + A1/AC:2019 |
| IP Rating | IP20 |
| Tightening Torque | en fazla 0.5 N.m (klemens) |
