Gwest IYF - 2.5 French Standard Insulated Cable Ferrule — Gray
- Brand: Gwest
- SKU: 2007
- MPN: IYF - 2.5
- Price: 193.00 TRY + VAT · incl. VAT 231.60 TRY
- Availability: In stock
- Insulated Single-Entry Ferrules
- Gwest Insulated Single-Entry Ferrules
- Selection guide: Insulated Single-Entry Ferrules Selection Guide: Technical Criteria and Engineering Practice
Gwest IYF - 2.5 French Standard Insulated Cable Ferrule. Key technical features - Cable Cross-Section: 2.50 mm² - Color: Gray - Material: Copper, Tin-Plated - Insulation: Nylon - Operating Temperature: Maximum 105 °C - Voltage: 600 V - Standard: DIN 46228 - Ferrule Dimension B: 7.4 mm - Ferrule Dimension W: 4.2 mm - Ferrule Dimension L: 14.0 mm - Ferrule Dimension D: 2.5 mm - Ferrule Dimension F: 8.0 mm
| Voltage | 600 V |
|---|---|
| Cable Cross-Section | 2.5 mm² |
| Material | Bakır, Kalay Kaplı |
| Color | Grey |
| Standard | DIN 46228 |
| Ferrule Dimension B | 7.4 mm |
| Ferrule Dimension D | 2.5 mm |
| Ferrule Dimension F | 8 mm |
| Ferrule Dimension L | 14 mm |
| Ferrule Dimension W | 4.2 mm |
| Operating Temperature | Maksimum 105 °C |
| Manufacturer Order Code | 2007 |
| Manufacturer Product Code | IYF - 2.5 |
| Product Type | Fransız Normu İzoleli Kablo Yüksüğü |
| Isolation | Naylon |
