KSN KLBV-2-3 Insulated Blade Terminal with Bent End 1.5-2.5 mm2 Blue
- Brand: KSN
- SKU: KSN3272
- MPN: KLBV-2-3
- Price: 258.30 TRY + VAT · incl. VAT 309.96 TRY
- Availability: In stock
- Blade Type Insulated Cable Terminals
- Selection guide: Insulated Cable Terminals Selection Guide: Technical Criteria and Engineering Practice
The KSN KLBV-2-3 is a blue, PVC-insulated, curved-end blade-type terminal used to connect conductors with a 1.5-2.5 mm² (16-14 AWG) cross-section to blade (flat-end) connections. Housing material is tin-plated copper; insulation is PVC, and the catalog gives a maximum operating temperature of 105 °C and a voltage of 600 V. Dimensions according to the catalog dimension drawing: B 3.0 mm, total length (L) 26.8 mm, F 16.8 mm, H 10.0 mm, D 4.9 mm. The product is listed in the catalog as a box of 100; sales are made in quantities of 100 and multiples. Used for connection to blade terminals in panels and control circuits.
| Cable Terminal Type | Ucu Kıvrık Bıçak Tip |
|---|---|
| Ferrule Size | 1.5–2.5 mm |
| Ferrule/Lug Insulation | İzoleli |
| Color | Blue |
| Cable Cross-Section | 1,50 - 2,50 mm² / 16 ~ 14 AWG |
| Material | Bakır, Kalay Kaplı |
| Isolation | PVC |
| Operating Temperature | Maksimum 105 °C |
| Voltage | 600 V |
| Dimension B | 3 mm |
| Length | 26.8 mm |
| Dimension F | 16.8 mm |
| Dimension H | 10 mm |
| Dimension D | 4.9 mm |
