Schneider Electric EZ9F59116 Pro MCB 1P C Curve 16A 10 kA

• Brand: Schneider Electric
• SKU: EZ9F59116
• MPN: EZ9F59116
• Price: 472.60 TRY + VAT · incl. VAT 567.12 TRY
• Availability: Made to order
• Miniature Circuit Breakers
• Schneider Electric Miniature Circuit Breakers
• Selection guide: Miniature Circuit Breakers Selection Guide
• Calculate current and breaker size from active power

Schneider Electric EZ9F59116 Pro MCB 1P C Curve 16A 10 kA. Technical specifications of this model: Rated Service Breaking Capacity (Ics): 10000 A 100 % CONFORMING TO IEC/EN 60898-1 - 240 V AC 50/60 Hz / 7.5 KA 75 % CONFORMING TO IEC/EN 60947-2 - 240 V AC 50/60 Hz Width: 18 mm Silicone-Free Declaration: No Connection Terminals: Tunnel terminals (bottom) 1…16 mm² Flexible; Tunnel terminals (bottom) 1…25 mm² Rigid Mains Type: AC Mechanical Endurance: 20000 CYCLES PVC-Free Declaration: No Series: Easy9 Pro 9 mm Number of Module Pitches: 2 Isolation Suitability: Yes, complies with IEC/EN 60898-1 Rated Current: 16 A IP Rating: IP20 CONFORMING TO IEC 60529 Manufacturer Standard Declaration: IEC/EN 60898-1IEC/EN 60947-2 Product Weight: 104 g Trip Unit Technology: THERMAL-MAGNETIC Tightening Torque: 2 N.M Short-Circuit Breaking Capacity: 10 kA Mounting Support: DIN rail Mains Frequency: 50/60 Hz Electrical Endurance: 10000 CYCLES Height: 85 mm Rated Operational Voltage: 240 V AC 50/60 Hz Comb Busbar and Distribution Block Compatibility: TOP: PIN TYPEBOTTOM: PIN/FORK TYPE Rated Insulation Voltage (Ui): 500 V AC 50/60 Hz CONFORMING TO IEC/EN 60898-1500 V AC 50/60 Hz CONFORMING TO IEC/EN 60947-2 Limitation Class: 3 Mounting Style: CLIP-ON Tropical Environment Protection: 2 CONFORMING TO IEC 60068-1 Manufacturer Certificate Declaration: TSECE Relative Humidity: 95 % AT 55 °C Storage Temperature: -40…85 °C Rated Impulse Withstand Voltage (Uimp): 4 KV CONFORMING TO IEC/EN 60898-14 KV CONFORMING TO IEC/EN 60947-2 Contact Position Indicator: Yes Toxic Heavy Metal-Free Declaration: ✓ Depth: 77 mm Product Type: Miniature Circuit Breaker Product Family: Easy9 XM devices Number of protected poles: 1 Halogen-Free Material Status: Product contains halogen above threshold values Tripping characteristic: C Control type: TOGGLE Device Application: DISTRIBUTION Operating Ambient Temperature: -30…70 °C Magnetic Trip Limit: 5...10 X IN CONFORMING TO IEC/EN 60898-18 X IN +/- 20 % CONFORMING TO IEC/EN 60947-2 Color: Gray (RAL 7035) Pollution Degree: 3 CONFORMING TO IEC/EN 60947-2 Short Device Name: Easy9 Pro MCB Pole arrangement: 1P Local Indicator: ON/OFF INDICATION Padlock Provision: Yes Breaking Capacity: 10000 A ICU AT 240 V AC 50/60 Hz CONFORMING TO IEC/EN 60898-110 KA ICU AT 240 V AC 50/60 Hz CONFORMING TO IEC/EN 60947-2
