Schneider Electric LTMTEFM TeSys Tera Main Module EtherNet 100-240VAC/DC
- Brand: Schneider Electric
- SKU: LTMTEFM
- MPN: LTMTEFM
- Price: 78287.16 TRY + VAT · incl. VAT 93944.59 TRY
- Availability: Made to order
- Motor Control Equipment
- Schneider Electric Motor Control Equipment
- Selection guide: Motor Control and Protection Equipment Selection Guide
- Schneider Electric LTMTEFM Teknik Veri Föyü (PDF)
Schneider Electric LTMTEFM TeSys Tera Main Module EtherNet 100-240VAC/DC. Technical specifications of this model: Series: TeSys Tera
| Series | TeSys Tera |
|---|---|
| Product Type | Motor kontrolörü |
| Device Application | Ekipman izleme ve kontrolü |
| Rated Control Supply Voltage (Us) | 100…240 V AC/DC 50/60 Hz |
| Current Consumption | 8–62.8 mA |
| Supply Voltage Limits | 85…265 V AC/DC |
| Communication Protocol | Ethernet TCP/IP |
| Fieldbus Type | Ethernet IEEE 802.3 arayüz, adresleme 0…159, aktarim hizi 10., 2xRJ45ile 4; shielding pairs cable |
| Rated Insulation Voltage (Ui) | 690 V AC (IEC 60185) |
| Short-Circuit Withstand Strength | 100 kA |
| Pollution Degree | 3 |
| Overvoltage category | III |
| Rated Impulse Withstand Voltage (Uimp) | 4 kV |
| Associated Fuse Rating | 0,5 A GG için kontrol devresi |
| Input current | 3 mA @ 100…240 V |
| Maximum Operating Rate (cycles/h) | 1800 cyc/h |
| Contact Arrangement | 2 NA hata sinyali; 1 NA + 1 NK hata sinyali |
| Connection Range | Besleme gerilimi için 7,5 mm; diğerleri için 5,0 mm |
| Width | 112 mm |
| Height | 45 mm |
| Depth | 90 mm |
| Web Services | Web sunucusu |
| Standards | EN/IEC 60947-4-1; UL/CSA 60947-4-1 |
| Certifications | UL; IEC; cUL |
| Fire Resistance | 650 °C (IEC 60947-1); 960 °C (UL 94) |
| Operating Ambient Temperature | -20…70 °C |
| Storage Temperature | -40…80 °C |
| Operating Altitude | <= 2000 m değer kaybı olmadan |
| IP Rating | IP20 |
