Tibcon 5 kVAr Single-Phase Harmonic Filter 7% - HRT-71235
- Brand: Tibcon
- SKU: TBHR5007
- MPN: TBHR5007
- Price: 3146.08 TRY + VAT · incl. VAT 3775.30 TRY
- Availability: In stock
- Single-Phase Harmonic Filters
- Selection guide: Single-Phase Harmonic Filters Selection Guide: Technical Criteria & Application Standards
Tibcon 5 kVAr Single-Phase Harmonic Filter 7% - HRT-71235. Single-Phase Harmonic Filters are used in power factor correction panels with drive and switching loads. Technical data: Power 5 kVAr. Stock code: TBHR5007.
| Power | 5 kVAr |
|---|---|
| Inductance | 2,5 mH |
| Current | 26,3 A (I rms) |
| Connection Type | Klemens |
| Product Net Weight | 6 kg |
| Reactor detuning factor | p=%7 |
| Resonance Frequency | 189 Hz |
| Standards | EN 61558-1, EN 61558 2-20, EN 60289 ve EN60076-6 |
| Frequency | 50 Hz (60 Hz Opsiyonel) |
| Inductance Tolerance | %3 |
| IP Rating | IP00 |
| Relative Humidity | %95 Yoğunlaşmayan (DIN 40040) |
| Maximum Operating Altitude Permissible | 0–2000 m |
| Thermal Protection | 120C (NC kontak) |
