Unit UPO1102CS 100MHz Dual-Channel Phosphor Display Benchtop Oscilloscope
- Brand: Unit
- SKU: UPO1102CS
- MPN: UPO1102CS
- Price: 20556.76 TRY + VAT · incl. VAT 24668.11 TRY
- Availability: Made to order
- Oscilloscopes
- Selection guide: Oscilloscopes Selection Guide: Technical Criteria & Application Standards
This Unit UPO1102CS is a 2-channel digital phosphor oscilloscope with 100 MHz bandwidth from the UNI-T UPO1000CS series. It has a sampling rate of 1 GS/s per channel and a memory depth of 56 Mpts; in fast acquisition mode it captures 500,000 waveforms per second. With Ultra Phosphor technology, 256 gray levels show the amplitude, time and intensity information of the signal together; 100,000 waveforms can be recorded and played back continuously in hardware. Offers triggering and hardware decoding for RS232, I2C, SPI, CAN and LIN serial buses, 1 M-point FFT and 36 automatic measurement parameters. Features a 7-inch 800 × 480 TFT display with USB Host, USB Device, LAN, external trigger and AUX output; SCPI commands and web-based control are supported. Suitable for electronic and electrical design, troubleshooting, education and industrial design.
| Bandwidth | 100 MHz |
|---|---|
| Analog Channels | 2 |
| Sampling Rate | 1 GS/s (kanal başına) |
| Memory Depth | 56 Mpts (kanal başına) |
| Rise Time | ≤ 3,5 ns |
| Waveform Capture Rate | 500.000 wfms/s (hızlı yakalama modunda) |
| Vertical Resolution | 8 bit |
| Vertical Scale | 1 mV/div – 20 V/div |
| Time Base | 2 ns/div – 1000 s/div |
| Maximum Input Voltage | 400 V (DC + Vpeak, 1 MΩ) |
| Serial Bus Trigger/Decode | RS232, I2C, SPI, CAN, LIN |
| Interfaces | USB Host, USB Device, LAN, EXT Trig, AUX Out |
| Supply Voltage | 100–240 V AC, 50/60 Hz, 100 VA |
| Display Size | 7 inç TFT, 800 × 480 |
| Product Dimensions | 306 × 138 × 124 mm |
| Gram | 3 kg |
