Unit UT3216 16-Channel Thermocouple Temperature Logger -200~1800°C 0.1°C 4.3-inch
- Brand: Unit
- SKU: UT3216
- MPN: UT3216
- Price: 38829.43 TRY + VAT · incl. VAT 46595.32 TRY
- Availability: Made to order
- Temperature Data Loggers
- Selection guide: Data Loggers Selection Guide: Technical Criteria and Engineering Practice
Unit UT3216 is a UT3200 series multichannel temperature logger with 0.1 °C resolution that measures temperature on 16 channels simultaneously using J, K, T, E, S, N, B and R type thermocouples. Technical values: 16 channels; measuring range −200.0 to 1800.0 °C (depending on thermocouple type); resolution 0.1 °C; thermocouple types J, K, T, E, S, N, B, R; fast and slow scanning; upper and lower limit alarm per channel; RS-232 and USB interfaces; 4.3-inch LCD; dimensions 340 × 214 × 89 mm, weight 3.5 kg. It offers numerical, bar chart and curve displays; the upper and lower temperature limit of each channel can be assigned to an alarm, and thermocouple short circuits are detected automatically. Data is saved to a USB drive and can be read from a computer via SCPI. It is used for multi-point temperature monitoring and logging such as in furnaces, heat treatment, product and battery tests.
| Alarm | Her kanal için alt ve üst sıcaklık limiti alarmı; yerleşik veri sıralama |
|---|---|
| Interfaces | RS-232, USB Device, USB Host; SCPI protokolü |
| Gram | 3.5 kg |
| Display | 4.3 inç LCD |
| Display Modes | Sayısal okuma, çubuk grafik ve eğri |
| Power Source | AC 100–240 V, 50/60 Hz |
| Calibration | Kanala özel kullanıcı kalibrasyonu |
| Channel Count | 16 |
| Temperature Resolution | 0.1 °C |
| Temperature Range | −200.0 °C – 1800.0 °C (termokupl tipine bağlı) |
| Thermocouple Accuracy | T: −150–0 °C ±1.0 °C, 0–400 °C ±0.8 °C; K: −100–0 °C ±1.2 °C, 0–1350 °C ±0.8 °C; J: −100–0 °C ±1.0 °C, 0–1200 °C ±0.7 °C; N: −100–0 °C ±1.5 °C, 0–1300 °C ±0.9 °C; E: −100–0 °C ±0.9 °C, 0–850 °C ±0.7 °C; S: −100–0 °C, 100–300 °C ve 300–1750 °C aralıklarında sırasıyla ±4.5 / ±3.0 / ±2.2 °C; R: 0–100 °C ±4.5 °C, 100–300 °C ±3.0 °C, 300–1750 °C ±2.2 °C; B: 600–800 °C ±5.5 °C, 800–1000 °C ±3.8 °C, 1000–1800 °C ±2.5 °C |
| Thermocouple Types | J, K, T, E, S, N, B, R |
| Data Logging | FAT biçimli USB bellek (harici sabit disk desteklenmez) |
| Measurement Rate | Hızlı ve yavaş tarama |
| Product Dimensions | 340 × 214 × 89 mm |
| Additional Functions | Termokupl kısa devre otomatik algılama; belirli kanalları tarama; tuş kilidi ve ekran görüntüsü (Print Sc) tuşu; menü dili Çince/İngilizce, tuş sesi ayarı; üst bilgisayar yazılımı |
| Standard Accessories | Güç kablosu, USB arayüz kablosu, 8 GB USB bellek, kanal tanımlayıcı, 2 grup K tipi termokupl test kablosu modülü UT-T21M (−100 – 200 °C) |
