Birtaş BIRTFLEX 575-CY / H05VVC4V5-K 3x1 mm2
- Brand: Birtaş Kablo
- SKU: 1010 07 003 2025
- Price: 23974.50 TRY + VAT · incl. VAT 28769.40 TRY
- Availability: Made to order
- H05VVC4V5-K Control Cables
- Selection guide: H05VVC4V5-K Control Cables Selection Guide: Technical Criteria and Engineering Practice
- Calculate cable current-carrying capacity
- Calculate voltage drop
Birtaş BIRTFLEX 575-CY / H05VVC4V5-K 3x1 mm2. Key technical features: Core cross-section: 3x1 mm2.
| Core Cross-Section | 3x1 mm² |
|---|---|
| Conductor | Flexible bare copper conductors, EN 60228 Class 5 |
| Insulation Material | PVC compound, EN 50363-3 / TI2 |
| Stranding | Cores stranded in layers with suitable lay length |
| Cable Shield | Tinned copper wire braid |
| Outer Sheath Material | PVC compound; EN 50363-4-1 / TM5, yağa dayanıklı |
| Outer Sheath Colour | ~RAL 7001, Grey |
| Rated Voltage | Uo/U: 300/500 V & 450/750 V |
| Test Voltage | 2500 V (AC 50 Hz) |
| Operating Temperature | Fixed: -40 °C … +80 °C; Flexible: -5 °C … +70 °C |
| Minimum Bending Radius | Fixed: 6 x D; Flexible: 15 x D |
| Conductor Resistance (20 °C) | EN 60228 acc. to Class 5 |
| Insulation Resistance | Min. 20 MΩ·km |
| Standards | EN 50525-2-51 |
| Flame Retardance / Fire Performance | Alev geciktirici testi: EN 60332-1-2 & IEC 60332-1-2 |
| Outer Diameter | Yaklaşık 9,40 mm (± %7) |
| Copper Weight | 52 kg/km |
| Oil Resistance | EN 60811-404 & IEC 60811-404acc. to; EN 50363-4-1/TM5; 7x24 saat @ 90 °C |
| Inner Sheath Material | PVC compound, EN 50363-4-1 / TM2 |
| Transfer Impedance | Max. 250 mΩ/m @ 30 MHz |
