Birtaş H05SSC4S-K(SIMH-C2-OZ) 16x1.5 mm2
- Brand: Birtaş Kablo
- SKU: 1715 08 016 2001
- Price: 150373.70 TRY + VAT · incl. VAT 180448.44 TRY
- Availability: Made to order
- Shielded SIMH Silicone Cables
- Selection guide: Shielded SIMH Silicone Cables Selection Guide: Technical Criteria and Engineering Practice
- Calculate cable current-carrying capacity
- Calculate voltage drop
Birtaş H05SSC4S-K(SIMH-C2-OZ) 16x1.5 mm2 is a product in the SIMH silicone cable product family of the Birtaş Kablo brand. Key technical features: Core cross-section: 16x1.5 mm2.
| Core Cross-Section | 16x1,5 mm² |
|---|---|
| Conductor | Flexible bare copper conductors, EN 60228 Class 5 |
| Separator Tape | Polyester bant veya beyaz sentetik bant |
| Inner Sheath | Silikon compound, Kırmızıkahve |
| Cable Shield | Tinned copper wire braid |
| Outer Sheath Colour | ~RAL 3016, Kırmızıkahve |
| Insulation Material | Silikon compound, EN 50363-1 / EI2 |
| Core Colour Code | OZ: EN 50334acc. to gri veya siyah damar üzeri mavi veya beyaz numaralar |
| Stranding | Cores stranded in layers with suitable lay length |
| Outer Sheath Material | Silikon compound, EN 50363-2-1 / EM9 |
| Standards | VDE 0250 & EN 50525-2-83 (design reference) |
| Conductor Resistance (20 °C) | EN 60228 acc. to Class 5 |
| Insulation Resistance | Min. 20 MΩ·km |
| Conductor Operating Temperature | +180 °C |
| Short-Circuit Temperature | +360 °C (5 saniye) |
| Rated Voltage | Uo/U: 300/500 V & 450/750 V |
| Test Voltage | 2500 V (AC 50 Hz) |
| Operating Temperature | Fixed: -60 °C … +180 °C; Flexible: -25 °C … +180 °C |
| Minimum Bending Radius | Fixed: 6 x D; Flexible: 15 x D |
| Flame Retardance / Fire Performance | Alev geciktirici: EN 60332-1-2 & IEC 60332-1-2; Devre bütünlüğü (FE180): IEC 60331-21; Halojensizlik: EN 60754-1/-2 & IEC 60754-1/-2 |
| Oil Resistance | EN 60811-404 & IEC 60811-404acc. to; EN 50363-2-1; 24 saat @ 100 °C |
| Outer Diameter | Yaklaşık 20,40 mm (± %7) |
| Copper Weight | 264 kg/km |
