Entes ENT.CF-230-5 Single-Phase Low Voltage Power Capacitor, 5kVAr, 230VAC
- Brand: Entes
- SKU: M1780
- MPN: M1780
- Price: 2732.17 TRY + VAT · incl. VAT 3278.60 TRY
- Availability: Made to order
- Single-Phase Power Capacitors
- Selection guide: Single-Phase Power Capacitors Selection Guide: Technical Criteria & Application Standards
Entes ENT.CF-230-5 Single-Phase Low Voltage Power Capacitor, 5kVAr, 230VAC. Single-Phase Power Capacitors are used for stepped or fixed reactive power correction in power factor correction panels. Technical values: Size Type 75x180mm, Voltage 230VAC. Stock code: M1780.
| Size Type | 75x180mm |
|---|---|
| Voltage | 230 V AC |
| Operating Frequency | 50/60 Hz |
| Capacitance Tolerance | %-5+%10 |
| Dielectric Losses | ≤0,3 W/kVAr |
| Operating Altitude | ≤2000 m |
| Test Voltage (Terminal-Terminal) | 2,15 x Un, AC 2 s |
| Test Voltage (Terminal-Case) | 3 kV, AC 10 s |
| Maximum Permissible Voltage | 1,1xUn |
| Maximum Permissible Current | 2 x In |
| Maximum Inrush Current | 100 In |
| IP Rating | IP00 |
| Discharge Resistors | Harici, 60 sn. sonra 50V |
| Standards | IEC 60831-1/2 |
| Rated Current (In) | 20.7 A |
