Erse COAXIAL MINI/U-6 Cu/Cu PVC Cable
- Brand: Erse Kablo
- SKU: FDER019600100065L
- MPN: FDER019600100065L
- Price: 3622.00 TRY + VAT · incl. VAT 4346.40 TRY
- Availability: Made to order
- Satellite-TV Broadcast Cables
- Erse Kablo Satellite-TV Broadcast Cables
- Selection guide: Satellite-TV Broadcast Cables Selection Guide: Technical Criteria and Engineering Practice
- Calculate cable current-carrying capacity
- Calculate voltage drop
Erse COAXIAL MINI/U-6 Cu/Cu PVC Cable is a product in the Erse Kablo brand's coaxial cable product family.
| Conductor | 0,65 mm Ø Elektrolitik Bakır |
|---|---|
| Insulation Material | 2,90 mm Ø Fiziksel Köpük PE |
| Cable Shield | 1. Ekran: Cu-Pes Bant (100% Kapama); 2. Ekran: Elektrolitik Bakır Örgü |
| Outer Sheath Material | PVC Kompaund |
| Outer Sheath Colour | Green |
| Outer Diameter | 4.4 mm |
| Insulation Resistance | >2000 MΩ·km |
| Capacitance | 53±2 pF/m |
| Velocity of Propagation | 82% |
| Operating Voltage | 1 kV |
| Test Voltage | 2500 V |
| Minimum Bending Radius | 20xCableØ |
| Operating Temperature | -40 °C … +70 °C |
| Impedance | 75 ± 3 Ω |
| Flame Retardance / Fire Performance | IEC 60332-1-2; DIN EN 60332-1-2; EN 60332-1-2 |
| Attenuation (20 °C) | 5 MHz: 2,88 dB/100m; 200 MHz: 14 dB/100m; 400 MHz: 19,3 dB/100m; 800 MHz: 29 dB/100m; 1000 MHz: 31,46 dB/100m; 2150 MHz: 48,1 dB/100m; 2400 MHz: 52 dB/100m; 3000 MHz: 57,65 dB/100m |
