Hes NAYY 1x400 mm2 YAVV Aluminum Cable
- Brand: HES Kablo
- SKU: HESWB0543
- Price: 33451.20 TRY + VAT · incl. VAT 40141.44 TRY
- Availability: In stock
- NAYY Aluminum Cables
- Selection guide: NAYY Aluminum Cables Selection Guide
- Calculate cable current-carrying capacity
- Calculate voltage drop
Hes NAYY 1x400 mm2 YAVV Aluminum Cable. Key technical features: Core cross-section: 1x400 mm2.
| Conductor | Bir veya çok telli alüminyum iletken |
|---|---|
| Insulation Material | PVC |
| Outer Sheath Material | PVC |
| Rated Voltage | 0,6/1 kV |
| Operating Temperature | Maksimum iletken sıcaklığı: 70 °C |
| Short-Circuit Temperature | Kesit ≤ 300 mm²: 160 °C; Kesit > 300 mm²: 140 °C (max. 5 sn.) |
| Minimum Bending Radius | 12 x D |
| Standards | TS IEC 60502-1 |
| Conductor Resistance (20 °C) | Max. 0,0778 Ω/km (DC) |
| Outer Diameter | Yaklaşık 32,6 mm |
| Current Carrying Capacity | Toprakta (20 °C): 572 A (yan yana), 496 A (üçgen demet); Havada (30 °C): 642 A (yan yana), 523 A (üçgen demet) |
