Hes NYY 1x35 mm2 YVV Underground Power Cable
- Brand: HES Kablo
- SKU: HESWB0322
- Price: 30369.60 TRY + VAT · incl. VAT 36443.52 TRY
- Availability: In stock
- NYY Cables
- HES Kablo NYY Cables
- Selection guide: NYY Cables Selection Guide
- Calculate cable current-carrying capacity
- Calculate voltage drop
Hes NYY 1x35 mm2 YVV Underground Power Cable is a product of the HES Kablo brand in the NYY underground power cable product family. Key technical features: Core cross-section: 1x35 mm2.
| Core Cross-Section | 1x35 mm² |
|---|---|
| Conductor | Bir veya çok telli bakır iletken |
| Insulation Material | PVC |
| Outer Sheath Material | PVC |
| Conductor Operating Temperature | Max. 70 °C |
| Short-Circuit Temperature | Kesit ≤ 300 mm²: 160 °C (max. 5 sn.) |
| Rated Voltage | 0,6/1 kV |
| Minimum Bending Radius | 12 x D |
| Standards | TS IEC 60502-1 |
| Outer Diameter | 12,5 mm (yaklaşık) |
| Conductor Resistance (20 °C) | Max. 0,524 Ω/km (DC) |
| Current Carrying Capacity | Toprakta 20 °C: yan yana 195 A, üçgen demet 165 A; Havada 30 °C: yan yana 169 A, üçgen demet 145 A |
