Isıso ICPN15-M30-A2 Capacitive Sensor, M30, PNP NO+NC, 15 mm
- Brand: Isıso
- SKU: ICPN15-M30-A2
- MPN: ICPN15-M30-A2
- Price: 911.65 TRY + VAT · incl. VAT 1093.98 TRY
- Availability: In stock
- Capacitive Sensors
- Selection guide: Capacitive Sensors Selection Guide: Technical Criteria & Application Standards
Isıso ICPN15-M30-A2, capacitive sensor (M30, PNP NO+NC, 15 mm). Technical specifications: Housing Type: M30; Output Type: PNP NO+NC; Sensing Distance: 15 mm; Connection Type: Cabled; Sensor Head Type: Non-flush; Supply Voltage: 10-30 V DC; Protection Rating: IP67; Operating Temperature: -25...+70 °C; Protection Features: Short-circuit, overload and reverse polarity protection; Load Current: 100 mA; Housing Material: Brass, nickel-plated. Stock code: ICPN15-M30-A2.
| Supply Voltage | 10-30 V DC |
|---|---|
| Body Type | M30 |
| Output Type | PNP NO+NC |
| Sensing Distance | 15 mm |
| Connection Type | Wired |
| Sensor Head Type | Çıkık (non-flush) |
| Load Current | 100 mA |
| Housing Material | Pirinç, nikel kaplama |
| Protection Rating | IP67 |
| Protection Features | Kısa devre, aşırı load ve ters polarite koruması |
| Operating Temperature | -25...+70 °C |
