Isıso IPN8-B18-E3 Inductive Sensor, Cubic, PNP NC, 8 mm
- Brand: Isıso
- SKU: IPN8-B18-E3
- MPN: IPN8-B18-E3
- Price: 335.17 TRY + VAT · incl. VAT 402.20 TRY
- Availability: In stock
- Square Type DC 3-Wire Inductive Sensors
- Isıso Square Type DC 3-Wire Inductive Sensors
- Selection guide: Square Type DC 3-Wire Inductive Sensors Selection Guide: Technical Criteria and Engineering Practice
Isıso IPN8-B18-E3, inductive sensor (Cubic, PNP NC, 8 mm). Technical specifications: Housing Type: Cubic; Output Type: PNP NC; Sensing Distance: 8 mm; Connection Type: Cabled; Sensor Head Type: Flush; Supply Voltage: 10-30 V DC; Protection Rating: IP67; Operating Temperature: -25...+70 °C; Protection Features: Short-circuit, overload and reverse polarity protection; Load Current: 100 mA. Stock code: IPN8-B18-E3.
| Supply Voltage | 10-30 V DC |
|---|---|
| Body Type | Kübik |
| Output Type | PNP NC |
| Sensing Distance | 8 mm |
| Connection Type | Wired |
| Sensor Head Type | Düz (flush) |
| Load Current | 100 mA |
| Protection Rating | IP67 |
| Protection Features | Kısa devre, aşırı load ve ters polarite koruması |
| Operating Temperature | -25...+70 °C |
