KSN KLBV-5.5-4.6 Insulated Blade Terminal with Bent End 4-6 mm2 Yellow
- Brand: KSN
- SKU: KSN3274
- MPN: KLBV-5.5-4.6
- Price: 483.00 TRY + VAT · incl. VAT 579.60 TRY
- Availability: In stock
- Blade Type Insulated Cable Terminals
- Selection guide: Insulated Cable Terminals Selection Guide: Technical Criteria and Engineering Practice
The KSN KLBV-5.5-4.6 is a yellow, PVC-insulated, bent-end blade-type terminal used to connect conductors with a 4-6 mm² (12-10 AWG) cross-section to blade (flat-end) connections. Body material is tin-plated copper; insulation is PVC, and the catalog gives a maximum operating temperature of 105 °C and a voltage of 600 V. Dimensions according to the catalog dimension drawing: B 4.6 mm, total length (L) 29.3 mm, F 16.8 mm, H 13.0 mm, D 6.7 mm. The product is listed in the catalog as a box of 100; sales are made in quantities of 100 and multiples. Used for connection to blade terminals in panels and control circuits.
| Cable Terminal Type | Ucu Kıvrık Bıçak Tip |
|---|---|
| Ferrule Size | 4–6 mm |
| Ferrule/Lug Insulation | İzoleli |
| Color | Yellow |
| Cable Cross-Section | 4,00 - 6,00 mm² / 12 ~ 10 AWG |
| Material | Bakır, Kalay Kaplı |
| Isolation | PVC |
| Operating Temperature | Maksimum 105 °C |
| Voltage | 600 V |
| Dimension B | 4.6 mm |
| Length | 29.3 mm |
| Dimension F | 16.8 mm |
| Dimension H | 13 mm |
| Dimension D | 6.7 mm |
