Lanbao PTFT-DM5DPR-E2 5mt Sensing Range, PNP NO+NC Output, Diameter Prismatic Retro-Reflective Photoelectric Sensor

Lanbao PTFT-DM5DPR-E2 5mt Sensing Range, PNP NO+NC Output, Diameter Prismatic Retro-Reflective Photoelectric Sensor

Lanbao PTFT-DM5DPR-E2 5mt Detection, Output PNP NO+NC, Diameter Rectangular Retro-Reflective Photoelectric Sensor is a Lanbao brand product in the rectangular photoelectric sensors category. Product code is PTFT-DM5DPR-E2. Lanbao PTFT-DM5DPR-E2 5 m Retro-Reflective Photoelectric Sensor, PNP Output (NO + NC), Prismatic Reflector, 10–30 V DC, 500 Hz, IP67 Lanbao PTFT-DM5DPR-E2, is an industrial optical photoelectric sensor that works on the retro-reflective (reflection from a prismatic reflector) detection principle. Detects presence up to 5 meters by stably sensing the return of light via the reflector. The IR LED light source in the transmitter allows the receiver to read the light returning from the prismatic reflector in a stable and noise-free manner. PNP transistor outputs (NO + NC) are suitable for sourcing input triggering and simultaneous inverse-logic status monitoring in PLC and DC automation panels. 500 Hz switching speed, provides reliable and repeatable triggering performance in short–medium range reflector applications. Technical Specifications Detection Distance: 0–500 cm ( 5 m, with prismatic reflector ) Detection Principle: Retro-Reflective (with prismatic reflector) Model / SKU: PTFT-DM5DPR-E2 Output: PNP transistor, NO + NC Switching Speed: 500 Hz Supply / Connection: 10–30 V DC, wired Protection Rating: IP67 Light Source: IR LED Operating Temperature: −25 °C … +55 °C Use Environment: Conveyors, production lines, gate/barrier control, panel and machine automation Applications Detection of opaque products, packages or objects up to 5 m Gate, barrier and passage control (reflector-based detection) PNP sourcing input triggering and NO/NC status monitoring on PLCs Reflector-based field automation applications requiring noise suppression Technical Information The sensor is of the retro-reflective class and must be used together with a prismatic reflector. For stable reading of the light returned from the reflector, the transmitter and reflector must be mounted coaxially . The output is PNP (sourcing output) type and connects as a sourcing input on the PLC. NO + NC signals provide simultaneous logic control and inverse status monitoring from a single sensor. Advantages: Lanbao PTFT-DM5DPR-E2 is a sensor solution that provides high stability in retro-reflective detection up to 5 m. PNP NO + NC dual transistor output enables both triggering and inverse-logic status monitoring from a single device, providing flexibility in PLC and DC panel applications. 500 Hz switching speed, offers noise-free and repeatable triggering performance in short and medium range reflector applications. IR LED light source provides strong immunity to ambient light and surface reflection interference. IP67 protection rating makes the sensor resistant to dust, moisture and water, providing high reliability and durability in harsh field conditions. The 10–30 V DC supply range allows direct, compatible integration with industrial DC control systems.
