Nexans HF NYA 1x10 mm2 H07Z1-U/R Halogen-Free Brown Cable
- Brand: Nexans Kablo
- SKU: NEXWB0108
- Price: 8302.70 TRY + VAT · incl. VAT 9963.24 TRY
- Availability: Made to order
- NYA Halogen-Free Cables
- Selection guide: NYA Halogen-Free Cables Selection Guide: Technical Criteria and Engineering Practice
- Calculate cable current-carrying capacity
- Calculate voltage drop
Nexans HF NYA 1x10 mm2 H07Z1-U/R Halogen-Free Brown Cable. Key technical features: 450/750 V; Core cross-section: 1x10 mm2.
| Core Cross-Section | 1x10 mm² |
|---|---|
| Color | Brown |
| Conductor | Tek veya çok telli bakır |
| Insulation Material | LSZH |
| Rated Voltage | 450/750 V |
| Standards | TS EN IEC 60228; TS EN 50525-3-31 |
| Flame Retardance / Fire Performance | TS EN IEC 60332-1-2; TS EN IEC 60754-1/2; TS EN IEC 61034-1/2; TS EN 50575 |
| Operating Temperature | -20 °C … +70 °C |
| Short-Circuit Temperature | 160 °C |
| Minimum Bending Radius | 4 x D (D ≤ 8 mm); 5 x D (D ≤ 12 mm); 6 x D (D > 12 mm) |
| Conductor Resistance (20 °C) | Max. 1,83 Ω/km (DC; CPR Cca tablosu) |
| Outer Diameter | yaklaşık 6,2 mm (CPR Cca tablosu) |
| Current Carrying Capacity | Havada 30 °C: 60 A (TS IEC 60364-5-52, düz aralıklı, yatay; CPR Cca tablosu) |
