Nexans HF NYAF 1x50 mm2 H07Z1-K Halogen-Free Red Cable
- Brand: Nexans Kablo
- SKU: NEXWB0312
- Price: 40977.00 TRY + VAT · incl. VAT 49172.40 TRY
- Availability: Made to order
- NYAF Halogen-Free Cables
- Selection guide: NYAF Halogen-Free Cables Selection Guide: Technical Criteria and Engineering Practice
- Calculate cable current-carrying capacity
- Calculate voltage drop
Nexans HF NYAF 1x50 mm2 H07Z1-K Halogen-Free Red Cable. Key technical features: 450/750 V; Core cross-section: 1x50 mm2.
| Core Cross-Section | 1x50 mm² |
|---|---|
| Color | Red |
| Conductor | Esnek bakır |
| Insulation Material | LSZH |
| Rated Voltage | 450/750 V |
| Standards | TS EN IEC 60228; TS EN 50525-3-31 |
| Flame Retardance / Fire Performance | TS EN IEC 60332-1-2; TS EN IEC 60754-1/2; TS EN IEC 61034-1/2; TS EN 50575 |
| Operating Temperature | -20 °C … +70 °C |
| Short-Circuit Temperature | 160 °C |
| Minimum Bending Radius | 3 x D (D ≤ 12 mm); 4 x D (D > 12 mm) |
| Conductor Resistance (20 °C) | Max. 0,386 Ω/km (DC; CPR Cca tablosu) |
| Outer Diameter | yaklaşık 13,2 mm (CPR Cca tablosu) |
| Current Carrying Capacity | Havada 30 °C: 212 A (TS IEC 60364-5-52, düz aralıklı, yatay; CPR Cca tablosu) |
