Nexans NYA 1x6 mm2 H07V-U Gray Cable
- Brand: Nexans Kablo
- SKU: NEXWB0073
- Price: 4671.70 TRY + VAT · incl. VAT 5606.04 TRY
- Availability: In stock
- NYA Cables
- Nexans Kablo NYA Cables
- Selection guide: NYA Cables Selection Guide
- Calculate cable current-carrying capacity
- Calculate voltage drop
Nexans NYA 1x6 mm2 H07V-U Gray Cable is a product in the H07V-U / NYA installation cable product family of the Nexans Kablo brand. Key technical features: 450/750 V; -20 °C to 70 °C operating range; EN 60332-1-2; Eca class; Cable type: H07V-U; Core cross-section: 1x6 mm2.
| Core Cross-Section | 1x6 mm² |
|---|---|
| Color | Grey |
| Conductor | Tek veya çok telli bakır |
| Insulation Material | PVC |
| Rated Voltage | 450/750 V |
| Operating Temperature | -20 °C … +70 °C |
| Short-Circuit Temperature | Max. 160 °C |
| Minimum Bending Radius | 4 x D (D ≤ 8 mm); 5 x D (D ≤ 12 mm); 6 x D (D > 12 mm) |
| Standards | TS EN IEC 60228; TS EN 50525-2-31 |
| Flame Retardance / Fire Performance | CPR sınıfı: Eca (TS EN 50575); Alev dayanımı: TS EN IEC 60332-1-2 |
| Outer Diameter | Yaklaşık 4,6 mm |
| Conductor Resistance (20 °C) | Max. 3,08 Ω/km (DC) |
| Current Carrying Capacity | Havada (30 °C, düz aralıklı, yatay): 43 A |
