Ortaç M 25 Standard Watertight Type Cable Gland Black (75 pcs/box)
- Brand: Ortaç
- SKU: OMRB06
- MPN: OMRB06
- Model: Siyah
- Price: 1094.40 TRY + VAT · incl. VAT 1313.28 TRY
- Availability: In stock
- Euro-Metric Sealed Type Glands
- Ortaç Euro-Metric Sealed Type Glands
- Selection guide: Euro-Metric Sealed Type Glands Selection Guide: Technical Criteria and Engineering Practice
Ortaç M 25 Standard Watertight Type Cable Gland Black (75 pcs/box). Standard Sealed Type Glands are used for sealing and strain relief at panel walls, machine housings and installation routes. Technical values: Gland Size Type Metric 25, Color Black. The product is sold in packs of 75. Stock code: OMRB06.
| Cable Gland Thread Type | Metrik 25 |
|---|---|
| Color | Black |
| Mounting Diameter | 25.5 mm |
| Thread Length | 10 mm |
| Clamping Diameter | 13–18 mm |
| Thread Size | M 25 x 1,5 |
| Wrench Size | 33 mm |
| RAL Number | RAL 9005 |
| Cover Material | Polyamid PA6 V2 |
| Housing Material | Polyamid PA6 V2 |
| Seal Material | TPV |
| Connection Thread | Metrik (EN 60423) |
| IP Rating | IP68 5 bar (o-ring ile) |
| Temperature Range | -20 °C +100 °C / -30 °C +150 °C (kısa süreli ısıya direnci) |
| Halogen Free | Yes |
