Ortaç PG 7 Standard Watertight Type Cable Gland Black (400 pcs/box)
- Brand: Ortaç
- SKU: ORB01
- MPN: ORB01
- Model: Siyah
- Price: 1988.80 TRY + VAT · incl. VAT 2386.56 TRY
- Availability: In stock
- Standard Sealed Type Glands
- Ortaç Standard Sealed Type Glands
- Selection guide: Standard Sealed Type Glands Selection Guide: Technical Criteria and Engineering Practice
Ortaç PG 7 Standard Watertight Type Cable Gland Black (400 pcs/box). Standard Watertight Type Glands are used for sealing and strain relief at panel walls, machine housings and installation routes. Technical values: Gland Size Type PG 7, Color Black. The product is sold in packs of 400. Stock code: ORB01.
| Cable Gland Thread Type | PG 7 |
|---|---|
| Color | Black |
| Mounting Diameter | 13 mm |
| Thread Length | 8 mm |
| Clamping Diameter | 3–6.5 mm |
| Wrench Size | 15 mm |
| RAL Number | RAL 9005 |
| Cover Material | Polyamid PA6 V2 |
| Housing Material | Polyamid PA6 V2 |
| Seal Material | TPV |
| Connection Thread | PG (DIN 40430) |
| IP Rating | IP68 5 bar (o-ring ile) |
| Temperature Range | -20 °C +100 °C / -30 °C +150 °C (kısa süreli ısıya direnci) |
| Halogen Free | Yes |
