Reçber SIMH 2x1 mm2 Cable
- Brand: Reçber Kablo
- SKU: 113110
- MPN: 113110
- Price: 3447.60 TRY + VAT · incl. VAT 4137.12 TRY
- Availability: In stock
- SIMH Silicone Cables
- Reçber Kablo SIMH Silicone Cables
- Selection guide: SIMH Silicone Cables Selection Guide: Technical Criteria and Engineering Practice
- Calculate cable current-carrying capacity
- Calculate voltage drop
Reçber SIMH 2x1 mm2 Cable is a product in the Reçber Kablo brand's SIMH silicone cable product family. Key technical features: Core cross-section: 2x1 mm2.
| Core Cross-Section | 2x1 mm² |
|---|---|
| Conductor | Stranded copper wire, Class 5, IEC 60228 |
| Insulation Material | Silikon yalıtım, EI2 EN 50363-1 |
| Core Colour Code | HD 308 S2 izole renk kodlamasına uygun |
| Outer Sheath Material | Silikon, EM9 EN 50363-2-1 |
| Outer Sheath Colour | RAL 2003 Kiremit Kırmızı |
| Operating Voltage | Max. 300/500 V |
| Test Voltage | 2000 V |
| Operating Temperature | Fixed: -50 °C … +180 °C; Flexible: -20 °C … +150 °C |
| Minimum Bending Radius | Fixed: 4 x D; Flexible: 8 x D |
| Conductor Resistance | Max. 19,5 Ω/km |
| Insulation Resistance | Min. 20 MΩ·km |
| Standards | EN 50525-2-83 |
| Flame Retardance / Fire Performance | Düşey alev yayılma: EN 60332-1-2; Düşey alev yayılma: EN 60332-3-24 “Category C”; Korozif gaz: EN 60754-1/2; Duman yoğunluğu: EN 61034-2; Akım sürekliliği: IEC 60331-21 FE180 |
| Outer Diameter | 6.6 mm |
| Copper Weight | 16 kg/km |
