Ünal NYAF 1x50 mm2 H07V-K Yellow-Green Cable
- Brand: Ünal Kablo
- SKU: UNALWB0191
- Price: 39780.30 TRY + VAT · incl. VAT 47736.36 TRY
- Availability: In stock
- NYAF Cables
- Ünal Kablo NYAF Cables
- Selection guide: NYAF Cables Selection Guide
- Calculate cable current-carrying capacity
- Calculate voltage drop
Ünal NYAF 1x50 mm2 H07V-K Yellow-Green Cable is a flexible single-core installation cable. Cable family: NYAF. Harmonized code: H07V-K. Conductor material: Copper. Insulation: PVC. Core size: 1x50 mm2. Color: Yellow-Green. The image is the manufacturer's representative family image; select the color, number of cores and cross-section according to the written specifications of the product.
| Core Cross-Section | 1x50 mm² |
|---|---|
| Color | Yellow/Green |
| Conductor | Fine-stranded copper conductor |
| Insulation Material | PVC (TI1) |
| Core Colour Code | TS 9758 |
| Rated Voltage | 450/750 V |
| Test Voltage | 1.5–2 kV |
| Operating Temperature | -20 °C … +70 °C |
| Short-Circuit Temperature | 160 °C |
| Minimum Bending Diameter | 6 x D |
| Conductor Resistance (20 °C) | Max. 0,386 Ω/km (DC) |
| Standards | TS EN 60228 (iletken direnci); TS 9758 (yalıtım direnci, yalıtkan); VDE 0100-430 (akım taşıma kapasitesi) |
| Flame Retardance / Fire Performance | TS EN 60332-1-2 |
| Outer Diameter | Yaklaşık 13,5 mm |
| Current Carrying Capacity | Toprakta (20 °C): 132 A; Havada (30 °C): 198 A |
