Ünal NYY 2x1.5 mm2 YVV Underground Power Cable
- Brand: Ünal Kablo
- SKU: UNALWB0314
- Price: 3457.90 TRY + VAT · incl. VAT 4149.48 TRY
- Availability: In stock
- NYY Cables
- Ünal Kablo NYY Cables
- Selection guide: NYY Cables Selection Guide
- Calculate cable current-carrying capacity
- Calculate voltage drop
Ünal NYY 2x1.5 mm2 YVV Underground Power Cable is a power cable. Cable family: NYY. Alternative designation: YVV (NYY). Conductor material: Copper. Insulation: PVC. Core size: 2x1.5 mm2. The image is the manufacturer's representative family image; select the color, number of cores and cross-section according to the written specifications of the product.
| Core Cross-Section | 2x1,5 mm² |
|---|---|
| Conductor | Tek telli bakır iletken (re) |
| Insulation Material | PVC/A |
| Core Colour Code | TS HD 308 S2 |
| Outer Sheath Material | PVC |
| Rated Voltage | 0,6/1 kV |
| Test Voltage | 3.5 kV |
| Operating Temperature | -20 °C … +70 °C |
| Short-Circuit Temperature | 160 °C |
| Conductor Resistance (20 °C) | Max. 12.1000 Ω/km (DC) |
| Standards | TS EN 60228 (iletken direnci); TS 60502-1 (yalıtım direnci); VDE 0100-430 (akım taşıma kapasitesi); TS HD 308 S2 (yalıtkan); TS IEC 60502-1 (dış kılıf) |
| Flame Retardance / Fire Performance | TS EN 60332-1-2 |
| Outer Diameter | Yaklaşık 11,5 mm |
| Current Carrying Capacity | Toprakta (20 °C): 32 A; Havada (30 °C): 20 A |
