Unit LM320E 4 x 90° ±0.2° Digital Angle Meter with 2-line Laser Indication

Unit LM320E 4 x 90° ±0.2° Digital Angle Meter with 2-line Laser Indication

Unit LM320E is a digital angle meter with a 2-line laser indication that measures angle over 4 × 90° with ±0.2° accuracy. The measurement range is 4 × 90° with ±0.05° resolution and ±0.2° angle accuracy and repeatability; the units are °, %, mm/m and in/ft. It provides relative and absolute angle measurement, angle hold and screen rotation. The 2-line laser indication has ±3 mm/5 m accuracy; the laser is Class 2, 630 – 670 nm and <1 mW. Its aluminum alloy frame, 1000 mAh lithium battery charged over Type-C and LED-backlit rotatable screen make it suitable for tilt and angle measurement in construction, mechanical installation, wood processing and the automotive industry. It measures 83.5 mm × 70 mm × 35.5 mm, weighs about 180 g and runs for 8 hours on a charge.

Measuring Range4 × 90°
Accuracy±0.2°
Resolution±0.05°
Laser Indication2 çizgi
Magnetic Baseİki yüzeyli (alt ve arka)
Charging InterfaceType-C
Additional FunctionsGöreceli/mutlak açı ölçümü, açı tutma, ekran döndürme, otomatik kapanma, LED arka ışıklı döner ekran
CertificationsCE, RoHS
Power Source1000 mAh lityum batarya
Operating Time8 saat
Product Dimensions83.5 mm × 70 mm × 35.5 mm
Gramyaklaşık 180 g
Standard AccessoriesAçı ölçer, Type-C kablo, hediye kutusu, kullanım kılavuzu
Repeatability±0.2°
Measurement Units°; %; mm/m; in/ft
MaterialAlüminyum alaşım gövde + ABS
Operating Temperature0 °C – +50 °C
Laser Accuracy±3 mm/5 m
Laser ClassClass 2
Laser Wavelength630 – 670 nm, <1 mW
