Entes ENT.CM-400-8.33 Single-Phase Low Voltage Power Capacitor, 8.33kVAr, 400VAC
- Brand: Entes
- SKU: M1877
- MPN: M1877
- Price: 1660.32 TRY + VAT · incl. VAT 1992.38 TRY
- Availability: Made to order
- Single-Phase Power Capacitors
- Selection guide: Single-Phase Power Capacitors Selection Guide: Technical Criteria & Application Standards
Entes ENT.CM-400-8.33 Single-Phase Low Voltage Power Capacitor, 8.33kVAr, 400VAC. Single-Phase Power Capacitors are used for stepped or fixed reactive power correction in power factor correction panels. Technical values: Size Type 65x165mm, Voltage 400VAC. Stock code: M1877.
| Size Type | 65x165mm |
|---|---|
| Voltage | 400 V AC |
| Operating Frequency | 50/60 Hz |
| Capacitance Tolerance | %-5+%10 |
| Dielectric Losses | ≤0,2 W/kVAr |
| Operating Altitude | ≤2000 m |
| Test Voltage (Terminal-Terminal) | 2,15 x Un, AC 2 s |
| Test Voltage (Terminal-Case) | 3 kV, AC 10 s |
| Maximum Permissible Voltage | 1,1xUn |
| Maximum Permissible Current | 4 x In |
| Maximum Inrush Current | 200 In |
| IP Rating | IP00 |
| Discharge Resistors | Harici, 60 sn. sonra 50V |
| Standards | IEC 60831-1/2 |
| Operating Temperature | -25+55°C |
| Rated Current (In) | 20.8 A |
| Power (230 V) | 2.76 kVAr |
