Hes N2XH 1x95 mm2 Halogen-Free Cable
- Brand: HES Kablo
- SKU: HESWB0406
- Price: 78120.00 TRY + VAT · incl. VAT 93744.00 TRY
- Availability: In stock
- N2XH Cables
- HES Kablo N2XH Cables
- Selection guide: N2XH Halogen-Free Power Cables Selection Guide
- Calculate cable current-carrying capacity
- Calculate voltage drop
Hes N2XH 1x95 mm2 Halogen-Free Cable is a product of the HES Kablo brand in the N2XH power cable product family. Key technical features: Core cross-section: 1x95 mm2.
| Core Cross-Section | 1x95 mm² |
|---|---|
| Conductor | Bir veya çok telli bakır iletken |
| Insulation Material | XLPE |
| Outer Sheath Material | HFFR |
| Rated Voltage | 0,6/1 kV |
| Operating Temperature | Maksimum iletken sıcaklığı: 90 °C |
| Short-Circuit Temperature | 250 °C (max. 5 sn.) |
| Minimum Bending Radius | 12 x D |
| Standards | TS IEC 60502-1 |
| Flame Retardance / Fire Performance | Halojensiz, alev iletmeyen |
| Conductor Resistance (20 °C) | Max. 0,193 Ω/km (DC) |
| Outer Diameter | Yaklaşık 17,5 mm |
| Current Carrying Capacity | Toprakta (20 °C): 366 A (yan yana), 310 A (üçgen demet); Havada (30 °C): 404 A (yan yana), 326 A (üçgen demet) |
