Mekas 2x1.5mm2 LIHCH Halogen Free Fire-Resistant Signal Cable FE180/PH120
- Brand: Mekas Kablo
- SKU: 71602
- MPN: 71602
- Price: 2317.80 TRY + VAT · incl. VAT 2781.36 TRY
- Availability: In stock
- LIHCH Fire-Resistant Cables
- Mekas Kablo LIHCH Fire-Resistant Cables
- Selection guide: LIHCH Fire-Resistant Cables Selection Guide: Technical Criteria and Engineering Practice
- Calculate cable current-carrying capacity
- Calculate voltage drop
Mekas 2x1.5mm2 LIHCH Halogen Free Fire-Resistant Signal Cable FE180/PH120. Fire-resistant cables are manufactured to keep the circuit operational for a specified time under flame; FE180/PH120 classes are common. Technical data: Core Cross-Section 2x1.50mm2, Cable Type LIHCH - FE180 HFFR. The product is sold per meter; the minimum order is 50 meters. Stock code: 71602.
| Core Cross-Section | 2x1,5 mm² |
|---|---|
| Cable Type | LIHCH - FE180 HFFR |
| Conductor | Bükülü Bakır Tel Class 5 |
| Insulation Material | Seramikleşen Silikon |
| Core Colour Code | DIN 47100 Renk Kodlu |
| Stranding | Katlar Halinde Büküm |
| Separator Tape | PES Bant |
| Flame Barrier | Cam Elyaf Bant |
| Outer Sheath Material | HFFR |
| Outer Sheath Colour | Orange |
| Operating Temperature | -30 °C … +70 °C |
| Minimum Bending Radius | 10 x D |
| Operating Voltage | 300/500 V |
| Conductor Resistance | 13,30 Ω/km |
| Test Voltage | 2500 V |
| Standards | TS 13755, EN 60228, EN 50290-2-26, EN 50290-2-27 |
| Flame Retardance / Fire Performance | EN 60332-1-2, EN 60754-1/2, EN 61034-2 |
| Cable Shield | Tinned copper wire braid |
