Ortaç PG 36 Standard Watertight Type Cable Gland Black (20 pcs/box)
- Brand: Ortaç
- SKU: ORB08
- MPN: ORB08
- Model: Siyah
- Price: 883.46 TRY + VAT · incl. VAT 1060.15 TRY
- Availability: In stock
- Standard Sealed Type Glands
- Ortaç Standard Sealed Type Glands
- Selection guide: Standard Sealed Type Glands Selection Guide: Technical Criteria and Engineering Practice
Ortaç PG 36 Standard Watertight Type Cable Gland Black (20 pcs/box). Standard Watertight Type Glands are used for sealing and strain relief at panel walls, machine housings and installation routes. Technical values: Gland Size Type PG 36, Color Black. The product is sold in packs of 20. Stock code: ORB08.
| Cable Gland Thread Type | PG 36 |
|---|---|
| Color | Black |
| Mounting Diameter | 47.5 mm |
| Thread Length | 13 mm |
| Clamping Diameter | 22–32 mm |
| Wrench Size | 53 mm |
| RAL Number | RAL 9005 |
| Cover Material | Polyamid PA6 V2 |
| Housing Material | Polyamid PA6 V2 |
| Seal Material | TPV |
| Connection Thread | PG (DIN 40430) |
| IP Rating | IP68 5 bar (o-ring ile) |
| Temperature Range | -20 °C +100 °C / -30 °C +150 °C (kısa süreli ısıya direnci) |
| Halogen Free | Yes |
