Reçber JE-H(St)H...Bd FE 180 PH120 1x2x1.5 mm2+0.80mm Cable
- Brand: Reçber Kablo
- SKU: 112071
- MPN: 112071
- Price: 5419.60 TRY + VAT · incl. VAT 6503.52 TRY
- Availability: In stock
- JE-H(St)H Fire-Resistant Cables
- Selection guide: JE-H(St)H Fire-Resistant Cables Selection Guide: Technical Criteria and Engineering Practice
- Calculate cable current-carrying capacity
- Calculate voltage drop
Reçber JE-H(St)H...Bd FE 180 PH120 1x2x1.5 mm2+0.80mm Cable. Key technical features: Core cross-section: 1x2x1.5 mm2.
| Core Cross-Section | 1x2x1,5 mm² |
|---|---|
| Conductor | Elektrolitik bakır tel |
| Insulation Material | Halojensiz, çapraz bağlı yalıtım, EI8 EN 50363-5 |
| Core Colour Code | DIN VDE 0815 izole renk kodlamasına uygun |
| Separator Tape | Pet bant min. %100 kapama; Cam elyaf bant min. %100 kapama |
| Outer Sheath Material | HFFR, 70°C EN 50290-2-27, HM2 DIN VDE 0207-24 |
| Outer Sheath Colour | RAL 2003 Turuncu |
| Operating Voltage | Max. 225 V |
| Test Voltage | 500 Vac (damar/damar); 2000 Vac (damar/ekran) |
| Operating Temperature | -30 °C … +70 °C |
| Minimum Bending Radius | 10 x D |
| Insulation Resistance | Min. 100 MΩ·km |
| Standards | TSE K 173, DIN VDE 0815 |
| Flame Retardance / Fire Performance | Düşey alev yayılma: EN 60332-1-2; Korozif gaz: EN 60754-1/2; Duman yoğunluğu: EN 61034-2; Akım sürekliliği: IEC 60331-21 FE180; Akım sürekliliği: EN 50200 PH120 |
| Capacitance | Max. 120 nF/km |
| Conductor Loop Resistance | Max. 24,2 Ω/km |
| Capacitance Unbalance | Max. 200 pF/100 m |
