Ünal N2XH 2x6 mm2 Halogen Free Cable
- Brand: Ünal Kablo
- SKU: UNALWB0396
- Price: 11907.00 TRY + VAT · incl. VAT 14288.40 TRY
- Availability: In stock
- N2XH Cables
- Ünal Kablo N2XH Cables
- Selection guide: N2XH Halogen-Free Power Cables Selection Guide
- Calculate cable current-carrying capacity
- Calculate voltage drop
Ünal N2XH 2x6 mm2 Halogen Free Cable is a halogen-free power cable. Cable family: N2XH. Conductor material: Copper. Insulation: XLPE. Sheath property: Halogen-free. Core size: 2x6 mm2. The image is the manufacturer's representative family image; select the color, number of cores and cross-section according to the written specifications of the product.
| Core Cross-Section | 2x6 mm² |
|---|---|
| Conductor | Bir veya çok telli bakır iletken |
| Insulation Material | XLPE |
| Core Colour Code | TS HD 308 S2 |
| Outer Sheath Material | HFFR |
| Rated Voltage | 0,6/1 kV |
| Test Voltage | 3.5 kV |
| Short-Circuit Temperature | 250 °C |
| Conductor Resistance (20 °C) | Max. 3,08 Ω/km (DC) |
| Standards | TS EN 60228 (iletken direnci); VDE 0276 (yalıtım direnci, yalıtkan, dış kılıf); VDE 0100-430 (akım taşıma kapasitesi) |
| Flame Retardance / Fire Performance | TS EN 60332-1-2; halojensiz |
