Ünal TTR 3x6 mm2 H05VV-F Black Cable
- Brand: Ünal Kablo
- SKU: UNALWB0245
- Price: 15346.00 TRY + VAT · incl. VAT 18415.20 TRY
- Availability: In stock
- TTR Cables
- Ünal Kablo TTR Cables
- Selection guide: TTR Cables Selection Guide
- Calculate cable current-carrying capacity
- Calculate voltage drop
Ünal TTR 3x6 mm2 H05VV-F Black Cable is a multi-core flexible connection cable. Cable family: TTR. Harmonized code: H05VV-F. Conductor material: Copper. Insulation: PVC. Core size: 3x6 mm2. Color: Black. The image is the manufacturer's representative family image; select the color, number of cores and cross-section according to the written specifications of the product.
| Core Cross-Section | 3x6 mm² |
|---|---|
| Color | Black |
| Conductor | Fine-stranded copper conductor |
| Insulation Material | PVC (TI2) |
| Core Colour Code | TS HD 308 S2 |
| Outer Sheath Material | PVC |
| Rated Voltage | 300/500 V |
| Test Voltage | 2 kV |
| Minimum Bending Diameter | 6 x D |
| Operating Temperature | -20 °C … +70 °C |
| Short-Circuit Temperature | 160 °C |
| Standards | TS EN 60228 (iletken direnci); TS 9760 (yalıtım direnci); VDE 0100-430 (akım taşıma kapasitesi); TS HD 308 S2 (yalıtkan, dış kılıf) |
| Flame Retardance / Fire Performance | TS EN 60332-1-2 |
