Unit UT3513 1μΩ-20kΩ 0.1% Accuracy 4.3-inch DC Micro Ohm Meter

• Brand: Unit
• SKU: UT3513
• MPN: UT3513
• Price: 21698.80 TRY + VAT · incl. VAT 26038.56 TRY
• Availability: Made to order
• Micro-Ohmmeters
• Selection guide: Electronic Measuring Instruments Selection Guide

Unit UT3513 is a UT3510 series bench micro ohm meter that measures DC resistance from 1 µΩ to 20 kΩ in 7 ranges with 0.1% basic accuracy in slow mode. Technical values: measuring range 1 µΩ to 20 kΩ (7 ranges); smallest resolution 1 µΩ; test current 1 A to 100 µA; basic accuracy 0.1% in slow mode and 0.2% in medium mode; maximum reading 22000; test speeds of 3 and 18 readings/s; four-terminal measurement; HANDLER, RS-232, USB Device and USB Host interfaces; 4.3-inch display; dimensions 214 × 89 × 340 mm, weight 3 kg. It sorts resistances into above upper limit, below lower limit and within range, and reports the result on the screen, with a buzzer and through external I/O outputs. It connects to a computer using the SCPI and Modbus protocols, and a temperature compensation line is supplied as standard. It is used to measure low-resistance parts such as coils, transformers, motors, relays, connectors and switches.
