Koç N2XH FE180 1x35 mm2 Halogen-Free Cable
- Brand: Koç Kablo
- SKU: KOCWB0360
- Price: 27272.30 TRY + VAT · incl. VAT 32726.76 TRY
- Availability: In stock
- N2XH FE180 Cables
- Koç Kablo N2XH FE180 Cables
- Selection guide: N2XH FE180 (E90) Fire-Resistant Power Cables Selection Guide
- Calculate cable current-carrying capacity
- Calculate voltage drop
The Koç N2XH FE180 1x35 mm2 Halogen-Free Cable is a product in the fire-resistant cable product family of the Koç Kablo brand. Key technical features: Core cross-section: 1x35 mm2.
| Conductor | Bir ya da Çok Telli Bakır İletken |
|---|---|
| Flame Barrier | Mika bant |
| Insulation Material | Çapraz Bağlı Polietilen (XLPE) |
| Outer Sheath Material | Halojen İçermeyen Alev Geciktiricili (HFFR) |
| Standards | TS HD 604 S1, VDE 0276 |
| Operating Temperature | Max. 90 °C |
| Minimum Bending Radius | 12 x D |
| Rated Voltage | 0,6/1 kV |
| Short-Circuit Temperature | Max. 250 °C |
| Outer Diameter | 11,7 mm (yaklaşık) |
| Conductor Resistance (20 °C) | 0,524 Ω/km (DC) |
