Nexans TTR 2x2.5 mm2 H05VV-F Black Cable
- Brand: Nexans Kablo
- SKU: NEXWB0373
- Price: 4784.40 TRY + VAT · incl. VAT 5741.28 TRY
- Availability: In stock
- TTR Cables
- Nexans Kablo TTR Cables
- Selection guide: TTR Cables Selection Guide
- Calculate cable current-carrying capacity
- Calculate voltage drop
Nexans TTR 2x2.5 mm2 H05VV-F Black Cable is a product in the TTR flexible cable product family of the Nexans Kablo brand. Key technical features: Cable type: H05VV-F; Core cross-section: 2x2.5 mm2.
| Core Cross-Section | 2x2,5 mm² |
|---|---|
| Color | Black |
| Conductor | Esnek bakır |
| Insulation Material | PVC |
| Outer Sheath Material | PVC |
| Rated Voltage | 300/500 V |
| Standards | TS EN IEC 60228; TS EN 50525-2-11 |
| Flame Retardance / Fire Performance | Alev dayanımı: TS EN IEC 60332-1-2; CPR sınıfı: Eca (TS EN 50575) |
| Operating Temperature | -20 °C … +70 °C |
| Short-Circuit Temperature | 160 °C |
| Minimum Bending Radius | 8 x D |
| Conductor Resistance (20 °C) | Max. 7,98 Ω/km (DC) |
| Outer Diameter | Yaklaşık 9,8 mm |
| Current Carrying Capacity | Havada 30 °C: 25 A (TS IEC 60364-5-52, tek kablo, yatay) |
